Homopolymeric Guanosine repeat of 20 nucleotides
rG20 is a 20-nucleotide homopolymeric RNA consisting entirely of guanosine residues and bearing a 5' triphosphate. As a continuous poly(G) RNA stretch, rG20 has a strong propensity to form stable G-quadruplex (G4) structures, four-stranded non-canonical RNA secondary structures stabilized by stacks of G-quartets, in which each quartet is a planar arrangement of four guanines linked by Hoogsteen hydrogen bonds and coordinated by monovalent cations such as K⁺. RNA G-quadruplexes are generally more thermally stable and compact than their DNA counterparts, owing to the 2'-hydroxyl group of the ribose sugar and the additional water-mediated contacts within the groove. The 5' triphosphate renders rG20 a potent innate immune activator: it is recognized by the cytosolic pattern recognition receptor RIG-I (retinoic acid-inducible gene I), which senses 5'-triphosphate single-stranded and double-stranded RNA to trigger type I interferon and proinflammatory cytokine responses. rG20 therefore serves as both a structural model for RNA G-quadruplex formation and a defined molecular tool for activating and studying innate immune signaling pathways.
Applications -
1) Lyu, K., Chow, E. Y.-C., Mou, X., Chan, T.-F., & Kwok, C. K. (2021). "RNA G-quadruplexes (rG4s): genomics and biological functions." Nucleic Acids Research, 49(10), 5426–5450
2) Hornung, V., et al. (2006). "5'-Triphosphate RNA is the ligand for RIG-I." Science, 314(5801), 994–997
3) Tosoni, E., et al. (2015). "Inhibition of retroviral production by RNA G-quadruplexes suggests a novel target for antiviral therapy." Biochemistry, 54(3), 691–693
4) Collie, G. W., Parkinson, G. N., Neidle, S., Bhatt, A., Jones, F., & Reszka, A. (2010). "Crystallographic and modelling studies of telomeric RNA G-quadruplex structures." Nucleic Acids Research, 38(16), 5569–5580
Cisterna's Off-the-shelf are validated to be purchased with a quick quote generated by the system. This means you go through a series of quick steps as below to complete your purchase. Step 1: If you already know the RNA you want, select the RNA you desire on the main page by clicking the 'Quality', 'Amount', and 'Quantity' on the main page and clicking on 'Add to Cart' button. If you want to read more about the individual RNA, click on the category of your RNA and select the RNA you desire by directly clicking on its name. This will take you to the individual RNA page, where you can learn more about the RNA, its usage in research with top examples for each of the use cases under the 'References' tab. Step 2: Once you are ready to order, just select the 'Quality', 'Amount', and 'Quantity', then click on 'Add to Cart' button. Step 3: After all the items have been added to the Cart, Click on 'Get a quote' button. Step 4: Fill in all of the information such as name, your professional email, and academic or business address. Note that non-professional emails and home addresses will not be considered. Step 5: Once the information is filled in, you may download the quote as PDF and save it for your reference. Step 6: You can then click on 'Continue to checkout' button which will take you to the final 'Checkout' page. Step 7: You can provide an optional Purchase Order (PO) number here as some institutions may require this. If everything looks ok, then click on 'Place an order'. Thats it! You are done. We will take it from here. We will make your RNA and ship in the fastest possible time. Invoices will be sent electronically to the email after confirmation of delivery. All invoices have a Net30 agreement.
PRIME is the standard quality RNA made by Cisterna. All RNAs including mRNAs are made with PRIME quality. The PRIME platform generates very low impurities such as dsRNA, short-truncated products, abortive transcripts and DNA:RNA hybrids. The result is a highly pure RNA that is functional and can be used for most downstream applications demanding high-purity such as X-ray crystallography, Cryo-EM, tRNA aminoacylation and to generate maximum amount of functional proteins.
Both PRIME and SPECC reflect Cisterna's commitment to high-quality RNA, but they are designed for different needs and applications. PRIME is Cisterna's standard production system and is applicable to all RNA types. It delivers very high purity RNA suitable for a wide range of demanding applications, from structural studies to functional protein expression. SPECC (SPEcific Capture and Cleavage) is Cisterna's flagship system and is currently applicable to mRNA only. It takes purity a step further by selectively isolating full-length mRNA transcripts, approaching HPLC-level purity. SPECC is the ideal choice when the highest possible mRNA quality is required, particularly for quantitative studies, high-dose applications, and therapeutic development. In terms of cost, SPECC is approximately 5-10x the price of PRIME, reflecting the advanced purification processes involved. While affordably priced, PRIME still delivers very high RNA quality, well above what you might expect at this price point.
